Product Information
1) Advanced construction for today’s demanding pilots
2) PATENTED quick assembly canopy, wings and elevator systems EXCLUSIVE to Skywing
3) Fast assembly time with pre-hinged and pre-sealed ailerons and elevators
4) Factory assembled detailed canopy interior
5) Incredible value NOW WITH MATCHING SPINNER, fuel tank, fuel line, fuel and vent dot, wing and stab bags, as well as preinstalled high quality extensions.
PRODUCT DATA
Wingspan 74 in./1880mm
Length 71.2 in./1809mm
Wing Area 1042.4 sq in/67.3dm²
Weight Gasoline settings; 11.9 lbs/5.4kg – Electric setting:11.02 lbs/5.0kg(6S/3700mah*2pcs)
Engine:DLE35RA
Servos Elevator, Aileron, Rudder, Throttle
Propellor:19 *8
Spinner:3”(76mm)
Servo arm Elevator 1.5″ *2, Aileron 1.5″ *2, Rudder 2.5″ *1 dual servo arm
REQUIRED:
1) 30-40cc Gas Engine
2) Propeller
3) Throttle Servo*1pcs
4) Digital High Torque Metal Gear Servos 40*20mm/20kg*5pcs
5) 6″ Extensions – aileron Throttle servos*3pcs
6) 1.5″ Arms – tapped for 3mm hardware (ailerons x 2, elevator x 2)
7) 3″ Double sided arm – tapped for 3mm hardware (rudder in push/pull config.)
Excludes SHIPPING, FLAT RATE @ INR 3,000
